| Ram | Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axle, Comfort Flat chainstays (Flatstays) design |
| Gaffel | RockShox Judy Gold RL 29, 100mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 30mm aluminum stanchions, offset 51mm. Settings: Onelock 2 pos remote compression (open/lock) |
| Bakdämpare | |
| Vevparti | SRAM SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm |
| Reglage | SRAM Trigger SX Eagle, 12s, |
| Bromsar | Sram Level |
| Bakväxel | Sram NX Eagle |
| Framväxel | |
| Kassett | SRAM PG-1230, 11-50T, 12s |
| Kedja | SRAM SX Eagle, 12s, Powerlock |
| Hjul | Fälg: MDK-XP1 29 TLR, 25mm internal width, tubeless ready, 32 spokes. Nav fram: Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts. Nav bak: Formula MST148S-4SB, Boost 12x148mm, sealed bearings, IS 6 bolts
|
| Däck | Maxxis Ikon 29x2.20, 3C MAXX SPEED compound, tubeless ready, 120TPI, folding bead |
| Styre | ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore |
| Styrstam | MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: size S: 60mm, size M: 70mm, size L: 80mm, size XL: 90mm |
| Sadel | Mondraker XC Series, steel rail |
| Sadelstolpe | ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm |
